CO2 laser tubes 50W

CO2 laser tubes 50W

Length 1000mm Pipe Diameter 50±1mm Wavelength 10.6um Output Power   Stable Value 50W Max Output Power 55W Triggering   Voltage 21-22KV Working Voltage 14-15KV Triggering   Current 4±1mA Max Working   Current 19mA Type Of Cooling Water-cooling 15-25℃ Impulse   Frequency 100% to 5KHZ Spot Diameter 3±1mm

Applications: co2 laser cutting/ engraving machine, works on non-metal materials,such as paper, leather, acrylic, fabric, wood, rubber, etc.

CO2 laser (laser tube) Installation instructions

1. Make sure the electrodes are connected correctly;

2. The cooling water pipe installation. When installing water pipe, please make sure the cooling water inlet must follow from the positive to negative, and down into the water, and the interface is not leaking. Before starting the laser tube must store enough water in the water cooling pipes and no air bubbles before use (must check every time before start laser tube). If the laser tube is mounted vertically, please ensure that no air bubbles at the top of the laser tube. It will cause thermal shock when it runs with air bubbles in the water pipe, which is easy to damage your laser tube.

3. To maintain the good performance of laser tube, keep the cooling water temperature between 20-25 °C. The instability of cooling water's temperature will influence laser tube output power.

4. When installing the laser tube, please try to ensure the 1/4 point in laser tube length is on laser tube holder, this can help your laser tube get best working performance. And leave enough space between the laser tube positive end (it has high voltage electricity) and any metal surface of your laser machine. If the space is not big enough, it will cause ignition between high voltage power used to trigger the laser tube and the metal surface of laser machine, and thus lead to laser tube damage and even breakdown of major electronic components on your laser machine.

5. Recommend laser machine consumers to put automatic checkout device into your laser tube water cooling system to prevent laser tube stoppage due to overheating failure caused by lack of water when laser tube is working, please consult your laser machine supplier for details.

CO2 Laser Tube Common Working Problems

Weak output laser power

1. Check if any scratches or dirt on laser tube output lens and the laser tube put on laser tube support at right point.

2. Check the output current of laser machine, service voltage, cooling water temperature, cleanness and rate of water flow.

3. Check the cleanness of focus lens and the reflectors on your laser machine, check whether the lens and reflective mirrors get hot or the laser beam is not well aligned.

High voltage electric discharge ignition

1. Check if any sundries around the high voltage electricity joint or the laser tube is too close to metal part of laser machine;

2. Too humid indoor environment will also cause electric conduction phenomena. Please pay attention to phenomenon of condensation water in laser tube when using water chiller in summer days.

3. Check if any contact defective or open circuit in laser power internal high-voltage connections.

Laser tube broken or the laser tube ends fallen off

1. Cooling water temperature must be 15 to 25 degrees. The cooling water can be frozen in cold area to cause laser tube broken from inside, so don’t leave any water within the laser tube when temperature is under 0 degree.

2. The tube must run under water protection device is on. (To test the tube lights or not with water supplied or not)

3. Check the silicon water pipe is folded or pressed by something.

4. Check if any bubbles in the laser tube.

5. Check whether the cooling water flow rate is normal and the water is circled from low to high.

If conditions 1-5 are normal, it is laser tube quality problem.

Laser tube breakdown caused by wrong operations of 1~5 conditions is not covered by warranty policy.
